| Product Type | ALC18 | ALC18E |
| Operating voltage | 230V AC |
| Frequency | 50Hz |
| Width | 1 modules |
| Installation type | Din rail |
| Glow lamp load | NC | 150mA |
| Setting range time | 0.5-20 min |
| Terminal Quantity | 4 |
| 1/2-way conductors | Automatic |
| Switching output | Potential-free and phase-independent |
| Method of connection terminal | Screw terminals |
| Incandescent/halogen lamp load 230V | 2300W |
| Fluorescent lamp load (conventional) lead-lag circuit | 2300W |
| Fluorescent lamp load (conventional) | 400 VA 42uF |
| parallel-corrected |
| Energy saving lamps | 90W |
| LED lamp < 2 W | 20W |
| LED lamp 2-8 W | 55W |
| LED lamp > 8 W | 70W |
| Fluorescent lamp load (electronic ballast) | 350W |
| Switching capacity | 10A (at 230V AC cos φ = 0.6 ) ,16A (at 230V AC cos φ = 1 ) |
| Consumed power | 4VA |
| Test approval | CE |
| Type of protection | IP 20 |
| Protection class | II according to EN 60 730-1 |
| Housing and insulation material | High-temperature resistant, self-extinguishing thermoplastic |
| Work temperature: | -10 ~ +50 °C (non-icing) |
| Ambient humidity: | 35~85% RH |
